Liquid Particle Size Analyzers

Categories: ,

CANTY particle sizing analyzers have been engineered to offer the user a means by which a liquid is analyzed while under varying pressures, temperatures and flow rates. It offers sample or continuous, microscopic, non-destructive viewing and provides particle size analysis with two dimensional results when used in conjunction with the CantyVisionClient™ Software. The vision system, with integral lighting, features precision optics designed to enhance the image prior to display or analysis. The analyzer utilizes a high resolution / high speed CCD/CMOS image sensor coupled to a microscopic lens system. The system offers zoom and focus ability, variable lighting, and multiple objective lens packages to cover a range of sizes. CANTY particle sizing systems feature a FUSEVIEW glass window that acts as a product contact barrier. Our unique fused glass windows far exceed all other glass windows in safety and performance allowing for high pressure ratings.

Liquid Particle Sizing – Generic from JM CANTY on Vimeo.

Product Description

Features:

• Particle Size, Shape and Distribution with Real Time Analysis

• Fused Glass Pressure Barrier Standard

• Ethernet color high resolution CCD/CMOS camera includes imaging software.

Product Inquiry

LAB REACTOR PARTICLE SIZING SYSTEM

Features:

• Crystallization monitoring in lab
• Seed size / count / concentration
• .7 um – 680 um particle size analysis

LAB TRUFLOW PARTICLE SIZING SYSTEM

Features:

• .7 um – 680 um particle size analysis
• 2D shape analysis
• Real time with visual verification

MACROFLOW PARTICLE SIZING SYSTEM

10 um – 2,400 um Particle size analysis range in a linear flow or recirculating loop.  This system is designed for lab use with varying pressures and temperatures.

LAB DILUTION PARTICLE SIZING SYSTEM

Unlike laser analysis which requires the dilution amount to be exact every time, the CANTY system requires a minimum dilution but no maximum dilution. This is demonstrated by the basin on top. It is achieved because visual measurement detects the particles unlike laser which detects light scattering.

INFLOW™ PARTICLE SIZING SYSTEM

.7 um – 4800 um Particle size analysis range for inline real time information.  This system is designed for inline use with varying pressures, temperatures, and pipe diameters.

CRYSTALSCOPE PAT PARTICLE SIZING SYSTEM

Features:

• In vessel measurement
• Seed control – .7 um -650 um
• Visual verification

IMMERSION PARTICLE SIZE MEASUREMENT SYSTEM

.7 um – 4800 um Particle size analysis range.  This system is designed to be submersed into the product for real time highly accurate process measurement.

INFLOW™ TURBIDITY MEASUREMENT SYSTEM

Features:

• In-line real time analysis
• Differentiate between particles & gas
• Visual verification

INFLOW™ PERCENT SOLIDS MEASUREMENT SYSTEM

Percent solids analysis using a high resolution CCD/CMOS image sensor that detects percent solids in fluids by measuring the transmittance of light. Using advanced software algorithms the system automatically removes gas bubbles from the analysis resulting in highly accurate and repeatable data outputs. This system is designed for inline use with varying pressures, temperatures, and pipe diameters.

INFLOW™ COLOR MEASUREMENT SYSTEM

Color analysis using a high resolution CCD/CMOS image sensor that detects color changes in fluids by measuring the transmittance of light. Using advanced software algorithms the system automatically removes gas bubbles from the analysis resulting in highly accurate and repeatable data outputs. This system is designed for inline use with varying pressures, temperatures, and pipe diameters.
