Showing 1–9 of 10 results
Canty High Temperature Cameras are ideal for demanding applications involving visual inspection or verification in extreme temperature environments between 750 F and 2500 F.
Eliminate costly maintenance for your belt scales!!! The CantyVision™ Volume Based Measurement System consists of a non-contact Ethernet camera that constantly analyzes product profile on a conveyor belt to produce an integrated volume with no maintenance required.
Canty pan & tilt systems have been designed for use in hazardous areas in accordance with explosion proof, and flame proof requirements. · Class I, Div. 1, Groups B, C & D · Class II, Div. 1, Groups E, F & G, & NEMA 4 areas · EEx d IIC T6, IP66
Canty High Temperature Cameras are ideal for demanding applications involving visual inspection or verification in extreme temperature environments.
The CANTY Molten Glass Level system consists of a high temperature surveillance camera, mounted to view the surface of the molten glass through an opening in the wall. On the wall directly opposite the camera, a reference point is created, often by simply removing a brick from the wall, or boring a hole though it. The position of the reflection of this reference point on the surface of the glass relative to the fixed mount camera, is directly related to the molten glass level. CantyVision™ software is configured to track the position of this reflection with accuracy to 0.001” (0.025mm). A cross-hair is displayed on the operator screen image at all times, to allow the user to visually verify what point is begin tracked by the software. Control outputs are available to the DCS via OPC, 4-20mA and Modbus TCP/IP.
Features:
Canty’s thermal vision system is quite similar to other radiative temperature methods, by measuring the energy produced by a process. The advancements in CCD cameras has allowed for the ability to measure wavelengths in both the visual range and near inferred range.
Canty Minitemp™ camera systems are a low cost, low maintenance, portable alternative to traditional high temperature cameras. Our unique design allows the unit to be easily moved from location to location in just minutes.
