Fuseview™ Industrial Sight Glass

All CANTY sight glasses feature the Fuseview™ window. Our unique fused glass windows far exceed all conventional tempered glass windows in safety and performance. By fusing glass to metal, a high pressure, high safety, hermetic seal is formed. The fused glass Technology ensures safety with every Fuseview™. What’s more, our windows can easily be removed for cleaning. CANTY windows do not have to be discarded, as do traditional tempered glass windows. CANTY fused glass windows can be re-used again and again.

FUSEVIEW from JM CANTY on Vimeo.

DIN Fuseview Flat Gasket Sight Glass PN – C10636

Glass Wetted Fuseviews – 96B6298

Fuseview With Quartz Shield – 96B6420

Fuseview MS Straight Thread Sight Glasses – 94B5071

Fuseview GS NPT Threaded Sight Glasses – 94A5058

Fuseview Cartridges Ordering Info – 94C5070

Fuseview Cartridge With Retainer Ordering Info – 94C5063

Fuseview 300# High Temperature Sight Glass PN’S – 94C5394

Fuseview 150# High Temperature Sight Glass PN’S – 94C5059

DIN Fuseview High Temperature Sight Glass PN – C10638

CANTY FuseView™ sight glasses have been engineered to meet all your process and safety needs. All standard FuseViews™ feature Factory Mutual approval and were designed and tested to ensure the safest product available. CANTY can provide certification of material and testing if required, typical of ASME code requirements for process vessels.

Features

  • Stainless, carbon, Hastelloy® C, Hastelloy® C276 or equal, and Hastelloy® C-22® or equal fusing rings
  • 150# through 2500# ANSI, 10 bar through 40 bar DIN models
  • Quartz and Sapphire shields for caustic service
  • FM Approved Models

Product Inquiry

DUAL HIGH TEMPERATURE FUSEVIEW™ SIGHT GLASS

CANTY Fuseview™ sight glasses have been engineered to meet all your process and safety needs. All standard Fuseviews™ were designed and tested to ensure the safest product available.

ANSI / DIN FUSEVIEW™ SIGHT GLASS

CANTY Fuseview™ sight glasses have been engineered to meet all your process and safety needs. All standard Fuseviews™ were designed and tested to ensure the safest product available.

NPT THREADED FUSEVIEW™ SIGHT GLASS

CANTY Fuseview™ sight glasses have been engineered to meet all your process and safety needs. All standard Fuseviews™ were designed and tested to ensure the safest product available.

GLASS WETTED FUSEVIEW™ SIGHT GLASS

The glass-wetted Fuseview™ is designed for use on glass lined reactors and other tanks where only glass is allowed in contact with the product.

JET SPRAY RING

The CANTY Jet Spray Ring generates a high pressure vortex rinsing action to remove tough deposits from sight glasses, lights, and vision systems.

SANITARY FLANGE FUSEVIEW™ SIGHT GLASS

CANTY Bolt-on Fuseviews™ are a fused sight glass providing one-piece construction with no additional gaskets or torquing required. CANTY Bolt-on Fuseviews™ were designed and tested to ensure the safest product available.

F700 SERIES FLANGED SIGHT FLOWS

CANTY F700 series flanged sight flows have been engineered to meet all your process and piping needs. Our sight flows have been designed to meet strict ASME code requirements. CANTY hydrotests all units to 150% of the maximum rated pressure and can provide certification of material and testing if required, typical of ASME code requirements for process vessels.

S100 SERIES THREADED/WELDED SIGHT FLOWS

CANTY S100 series threaded/welded sight flows have been engineered to meet all your process and piping needs. Our Sight flows have been designed to meet strict ASME code requirements. CANTY hydro-tests all units to 150% of the maximum rated pressure and can provide certification of material and testing if required, typical of ASME code requirements for process vessels.
