PARTICLE SIZING

Showing 1–12 of 36 results

Single Use

Single Use Applicatons

  • Level Monitoring
  • Foam Control
  • Turbidity
  • Particle Size Analysis

Fermentation

CANTY imaging systems have been involved in the control to improve yield of fermentation for several years. Measurement of cell size, concentration and viability in real time in batch and perfusion type fermentation is critical to the process yield. The measurement of foam allows operators independent control of anti-foam additions. The measurement of cell size, count, viability and concentration in the lab or at-line is accomplished by our imaging based system which can distinguish a cell form a gas bubbles and other trace particles.

Liquid Analysis / Turbidity / CIP

Liquid  analysis using a high resolution CCD/CMOS image sensor that detects turbidity changes in fluids by measuring the transmittance of light. Using advanced software algorithms the system automatically removes gas bubbles from the analysis resulting in highly accurate and repeatable data outputs. This system is designed for inline use with varying pressures, temperatures, and pipe diameters.

Sub-Visible Particles

Features:

• Particle size / shape / count

• In-line and lab options

• Visual Verification

Chromatography Beads

Features:

• Bead size

• Visual Verification

• Differentiate between particles and gas

WFI – Water For Injection

Features:

• In-line real time concentration analysis

• Differentiate between particles & gas

• Visual Verification

PAINT & PIGMENT PARTICLE SIZING SYSTEM

Features:

• Particle size and count of solids/water

• 1um – 300um in particle size analysis

• CCD/CMOS Based High-Speed Imaging Device

LAB DILUTION PARTICLE SIZING SYSTEM

Unlike laser analysis which requires the dilution amount to be exact every time, the CANTY system requires a minimum dilution but no maximum dilution. This is demonstrated by the basin on top. It is achieved because visual measurement detects the particles unlike laser which detects light scattering.

Cell Count / Viability / Size

Features:

• Analyze cells down to .7 micron

• No terrapin dye needed

• 2.5 minutes to run an 8mL sample

FERTILIZER / UREA ANALYSIS – SOLIDSIZER

Features:

• Correlates to Sieve Results within 2%

• Particle distribution by major, minor diameter, area, perimeter

• Real time particle size analysis



SUGAR LAB – SOLIDSIZER™ WITH COLOR ANALYSIS

10 um – 2,400 um Particle size analysis range.  Finished sugar product is subjected to a series of quality control tests in order to determine if the sugar crystals are the correct size and shape, and also that the concentration of black specks / burned sugar crystals is within specification. CANTY’S range of image based particle analysis systems provide true size and shape characterization, with each particle measured under 13 size and shape parameters. CANTY’S imaging systems also offer the option of Black Speck detection within the sugar sample. The systems can be run at line through the use of a sweep sampler, or offline as laboratory instruments. This system provides direct correlation to traditional sieve analysis, but does so in a much shorter analysis time, with much less operator input required

FRAC SAND ANALYSIS – SOLIDSIZER

Features:

• Correlates to Sieve Results within 2%

• Particle distribution by major, minor diameter, area, perimeter

• 2 min analysis for 100g
