TURBIDITY

Showing 1–9 of 13 results

BATCH FILTERS

Batch filtration is a method to separate solid particles from a liquid by retaining the solids on a filter medium while allowing the liquid (filtrate) to pass through, typically in a single, contained vessel rather than a continuous flow. This method is often used for small-scale applications.

Monitoring turbidity with CANTY systems in batch filtration is crucial for ensuring filtration efficiency, detecting filter failure, controlling product quality, and optimizing the process. In-line turbidity measurements provide real-time data, allowing operators to make adjustments and maintain process control.

MORE INFO
CENTRIFUGES

A centrifuge operates continuously, harnessing centrifugal force to separate components within a slurry based on their density. As the mixture spins at high speeds, heavier solids are efficiently extracted. This method excels in handling large volumes with consistent performance, making it a reliable solution for high-throughput processing.

The Canty Inflow™ is an excellent tool for controlling a centrifuge to determine percent solids and turbidity of filter breakthrough in the effluent stream, where product is being washed away. This is measured in-line in the effluent stream after the centrifuge.

MORE INFO
LIQUID ANALYSIS / TURBIDITY / CIP

The CANTY liquid analysis units use cameras to detect turbidity, CIP, and other desired process parameters. Liquid analysis using a high resolution CCD/CMOS image sensor that detects turbidity changes in fluids by measuring the transmittance of light. Using advanced software algorithms the system automatically removes gas bubbles from the analysis resulting in highly accurate and repeatable data outputs. This system is designed for inline use with varying pressures, temperatures, and pipe diameters.

MORE INFO
PHARMA INFLOW™ TURBIDITY MEASUREMENT SYSTEM

Turbidity analysis using a high resolution CCD/CMOS image sensor that detects turbidity changes in fluids by measuring the transmittance of light. Using advanced software algorithms the system automatically removes gas bubbles from the analysis resulting in highly accurate and repeatable data outputs. This system is designed for inline use with varying pressures, temperatures, and pipe diameters.

MORE INFO
SUGAR

While the basics of mass sugar refining have not changed significantly in the last 200 years, it is important to take advantage of relatively newer technology to allow the production processes to run more efficiently and produce a higher yield. CANTY’s range of dynamic imaging systems can be used to do just that, by providing unparalleled views into the process, and generating useful data that can be used for process control and optimization. Sugar production processes where the CANTY vision based instrumentation can be employed include clarifying, crystallization, centrifuging, and product quality control.

MORE INFO
Sugar Pan – Fuseview™

The Fuseview™ eliminates the chance of glass getting into the evaporators or sugar pans by over torque of the operators. Also, it allows for the sugar pan to pull full vacuum unlike tempered glass.

MORE INFO
CENTRIFUGE – CAMERA

CANTY’s dynamic imaging technology uses a combined camera & light system mounted to the top of the centrifuge, to provide a remote view of the process conditions in the control room. The system can also be used in conjunction with CANTYVISION image analysis software to provide important process measurements. In a continuous centrifuge, the system can track the position of the color line, allowing the operator to adjust the feed conditions to maintain a relatively stationary color line position and optimize washing efficiency. In a batch centrifuge, the system can measure the product or “cake” thickness on the basket wall during filling, and determine when the product is dry enough after spinning, to move onto the next production stage without material quality / handling issues that may be caused by high moisture content.

MORE INFO
CENTRIFUGE – TURBIDITY MONITOR

The Canty Inflow™ is an excellent tool for controlling a centrifuge to determine percent solids & turbidity of filter breakthrough in the effluent stream, where product is being washed away. This is measured in-line in the effluent stream after the centrifuge.

MORE INFO
CLARIFIER – TURBIDITY MONITOR

CANTY provides a direct inline color & turbidity analyzer, to analyse the fluid discharged from the clarification process, in order to determine if it is within specification. Combining CANTY’s imaging, fused glass and lighting technologies, the colour of the liquid can be analysed on a number of color scales (YUV, RGB, Lab), which can be taken as a direct measurement, or related to a specific NTU or FTU turbidity value. The image analysis software has the ability to filter out any air bubbles from the analysis, meaning only a true color / turbidity measurement is performed on the fluid.

MORE INFO
